Description
Split cords of seasoned firewood without hauling massive hydraulic trailers into tight residential backyards. The Champion Power Equipment 8-Ton Compact horizontal gas log splitter delivers 16000 lbs of hydraulic force. This compact machine runs on an 80 cc OHV gas engine. The horizontal frame requires ground-level log positioning, limiting work to logs under 19 inches long.
Heavy-gauge channel steel forms the low-profile chassis, resisting torsion during stubborn cross-grain splits. The 80 cc four-stroke engine drives an internal gear pump that pushes hydraulic fluid through a 3-inch bore cylinder. An automatic return control valve shifts the ram back into retracted position once the split completes. Integrated steel log cradles hold cut rounds on the beam, while pneumatic transport wheels permit transit across turf lawns without leaving wheel ruts.
Key Features of Champion 201466
Groundskeepers use this compact splitter to process fireplace timber from downed tree limbs. The low machine weight allows single-operator transport into remote wooded clearings.
- 8-ton hydraulic force splits seasoned oak, maple, and pine logs up to 19 inches long
- 80 cc four-stroke gas engine provides dependable mechanical power without electrical cords
- Automatic return valve resets the hydraulic cylinder to stroke start position
- 20-second cycle time balances hydraulic pressure with fuel efficiency during continuous splits
- Hardened steel splitting wedge cuts cross-grained firewood blocks without edge deformation
- Integrated steel log cradles keep timber centered along the splitting beam
- Pneumatic wheels and front handle facilitate transit over lawn turf and garden soil
Hydraulic Splitting Bench Test Telemetry
Pressure transducers measure 3100 PSI inside the cylinder barrel at peak splitting resistance in dry oak. Cycle tests clock a 19.4-second full extension and return stroke under continuous operation. Fuel consumption averages 0.22 GPH under moderate engine load. Sound pressure registers 82 dBA at the operator position. Hydraulic fluid thermal rise measures 18 degrees Fahrenheit above ambient conditions after two hours of continuous timber processing.
Firewood Processing Rules Safety Guardrails
Position the machine on level ground and chock the wheels before pulling the engine recoil starter. Set log rounds flat against the base push plate to eliminate uneven side loads on the cylinder rod. Never place hands along the beam rail while the hydraulic ram advances toward the wedge.
- Engine crankcase requires 10W-30 small engine oil changes every 50 working hours
- Hydraulic reservoir demands ISO 32 anti-wear fluid checks before every splitting session
- Beam rail top plate requires coatings of multi-purpose grease to stop dry slide friction
Champion Power Splitter Warranty Manifest
Champion Power Equipment backs this log splitter with a 2-Year limited warranty covering engine defects and hydraulic components. The shipment includes the 8-ton log splitter assembly, oil funnel, hardware pack, and engine operator manual.
