Description
Estate lawn care drags when handheld wand spraying requires stopping the mower every few minutes to cover weed patches. The Agri-Fab 15 Gallon Zero Turn Sprayer with Boom mounts directly to commercial zero-turn mower rear frames to apply turf herbicides and fertilizers on the move. It carries 15 Gallons of spray solution. Rear-mounted liquid weight lightens front caster contact on steep grades.
The tank features thick rotationally molded translucent polyethylene with molded gallon and liter volume calibration marks. A heavy-duty powder-coated steel bracket assembly mounts directly to standard mower hitch points without chassis flex. The 12 Volt electric diaphragm pump utilizes chemically resistant Viton valves and a Santoprene diaphragm to handle standard lawn care fertilizers and broadleaf herbicides.
Turf Chemical Application Hardware Platform
A compact folding boom allows zero-turn operators to spray wide turf paths and quickly flip the wings up to clear tight garden gates. The included hand wand handles spot treatments around trees and flower beds.
- 15 Gallon durable translucent poly tank lets operators monitor liquid levels while driving the mower.
- 12 Volt electric diaphragm pump delivers 1.0 GPM fluid flow at 40 PSI working spray pressure.
- Rear folding spray boom provides 50 inches of even broadcast spray coverage across open turf.
- Commercial-grade hand spray wand with 15 feet of hose reaches tight shrubs and perimeter fence lines.
- Remote wiring harness includes an in-line power switch to engage spraying from the mower control console.
- Universal mounting brackets bolt onto most major commercial zero-turn mower rear hitch plates.
- Spring-loaded boom breakaways protect the outer spray nozzles from impact with fence posts and trees.
Electric Pump Current Bench Telemetry
The 12 Volt diaphragm pump draws 4.2 Amps from the zero-turn mower charging system during steady 40 PSI boom spraying. Electric pump motor casing temperatures level out at 122°F after one hour of continuous turf treatment. Fluid pressure across the two boom nozzles remains stable at 36 PSI. Operating sound output from the isolated electric pump registers only 54 dBA at the mower seat.
Turf Maintenance Bounds Care Guidelines
Residential landscape maintenance crews and large estate caretakers gain rapid spot-spraying efficiency with this compact zero-turn setup. Do not buy this unit for extensive multi-acre pasture spraying because the 15-gallon volume requires excessive refilling on large properties. Never leave concentrated chemical solutions sitting inside the diaphragm pump housing between weekly mowing cycles.
- Triple-rinse the poly tank with fresh water and pump clean water through the boom after every application.
- Clean the tip strainers behind each boom spray nozzle every 20 hours to maintain flat fan spray patterns.
- Inspect the 12 Volt wiring harness for chafing against sharp mower frame edges after every work shift.
Equipment Warranty Unboxing Hardware Manifest
Agri-Fab backs this zero-turn sprayer with a 3-Year limited consumer warranty covering the poly tank, electric pump, and steel brackets. The unboxed shipment includes the 15 Gallon poly tank, 12 Volt pump, 50-inch folding boom, hand spray wand, 15-foot hose, wiring harness with switch, and mounting hardware.
