Description
The 7118420 Unloader Valve replacement kit with hardware is a replacement modular unloader valve to replace the previous style Banjo Bolt series AAA unloaders.
This new style unloader replacement kit with hardware features a new interior design for more efficient flow & operation.
A fatigue resistant spring with powder paint is installed to resist rusting.
This Unloader is designed to respond to an increase in pressure and a change in flow or for variable pressure adjustment.
Technical Specifications:
- Max Temperature: 194 degrees F
- Max PSI: 4500
- Inlet Port: 3/8 inch
- Outlet Port: 3/8 inch
- Max GPM: 10.5
- Built In EZ Start System
- Vibration resistant dual locking nuts for setting maximum pressures
- Larger diameter piston for more strength and contact area for shifting alignment
- Discharge nipple sealing o-ring has been moved to the lower part of the thread to increase hydro strength and fitting strength
- Shutter valve hex design means less contact area for smooth shifting, prevents binding, larger size for longer life more positive shifting
- Two inlet ports
- Two by-pass ports
- Ultra-thick inlet and discharge ports for added strength
- All ports are FNPT
