Description
Description:
Features:
- Commercial-grade 25.5 hp Kawasaki FX801V (852cc) engine
- A fully fabricated 54-inch 10-gauge steel commercial deck shell with top bottom and side reinforcements plus standard 24″ tires give you more ground clearance to easily hop on curbs.
- A large, fully adjustable suspension platform allows you to adjust tension and glide comfortably through tough terrains.
- High-performance commercial Hydro-Gear PK 12cc pumps & Parker TL 240cc wheel motors deliver quick response to the drive wheels and smooth control for cutting speeds up to 10 mph.
- 3-year limited commercial warranty (no hour limitations) and 5-year/1,750-hour limited deck assembly warranty.
Specifications:
Engine
- Brand: Kawasaki
- Model: FX Series, Model Number 801V
- Displacement: 852cc
- Output: 25.5 HP
- Starter Type: Electronic
- Fuel Tank Capacity: 7.5 gal. US (28.4 L)
- Cylinders: Twin
- Start Type: Ignition Key
- Oil Capacity: 2.0 qt. US (1.89 L)
- Lubrication: Fully pressurized
- Charging System: 15 amp regulated
- Fuel Gauge: Not included
- Choke: Separate Choke
- Air Filter: High Density
- Oil Filter: Yes
- Fuel Delivery: Carburetor
Drive System
- Transmission: 12cc Hydro-Gear pumps / 240cc Parker wheel motors
- Forward Speed: 10 mph (16 km/h)
- Reverse Speed: 5 mph (8 km/h)
Cutting Deck
- Width: 54 in
- Material: 10-gauge steel
- Engagement (PTO): Electronic with quick reset
- Construction: 10-gauge shell with 7-gauge top & bottom reinforcement
- Spindle Construction: Heavy-duty 8″ aluminum housing, 35mm double-row sealed ball bearings, 1-3/8″ through-shaft, maintenance-free
- Blades: Three 19″ high-lift Marbain blades, 1-1/2″ overlap
- Deck Lift: Hand lever adjusting spring lift with pin selector for height
- Cutting Height Range: 1.5″ – 4.5″
- Anti-Scalping: 2 front deck gauge wheels
Chassis
- Frame: 2″ x 3″ full-length tube frame
- Front Axle: 2″ x 3″ tube construction
- Front Caster Mount: 3/8″ thick steel
- Suspension: Hand lever adjust, 3-position spring suspension foot platform
Controls
- Brakes: Hand lever control / external band
- Steering: Lap Bar Steering Wheel Control
Wheels
- Rear Tires: 24″x12″-12″
- Front Tires: 13×5-6″ Reliance Run Flat Carlisle
Dimensions
- Length/Width/Height: 69″ / 68″ / 56″
- Weight (approx.): 1080 lbs
Additional Specifications
- Hour Meter: Crew Boss
- Model Number: 53AI8CSA050
- Residential Warranty: 3-year / no-hour-limit
- Deck Shell Warranty: 5-year / 1,750-hour limited manufacturers warranty
| Width | Weight | Height | Length |
|---|---|---|---|
| 68Inch | 1080Pounds | 56Inch | 69Inch |
