Description
Transport dedicated washing capacity to distant pasture gates and farm equipment sheds. The Agri-Fab 60 Gallon Poly Tank washer provides mobile cleaning power behind utility tractors. A 208cc gas engine turns a direct-drive axial pump. The unbaffled tank design creates fluid surge that requires careful tractor throttle control on hills.
A powder-coated welded steel cart chassis supports the thick polyethylene fluid tank. The 208cc commercial gas engine connects directly to an aluminum-head axial pump. Pneumatic 15-inch turf tires spread the gross liquid weight across soft soil without tearing turf. A clevis hitch pin couples the cart to lawn tractors and utility vehicles. An integrated wand bracket holds the spray lance secure.
Tow Behind System Specifications
Groundskeepers clean remote park fences and estate buildings without hose connections. The onboard tank holds enough water for remote washing cycles away from hydrants.
- Commercial 208cc gas engine delivers steady rotational drive for mobile wash tasks
- Direct-drive axial cam pump produces 2700 PSI at 2.5 GPM water flow
- Thick 60-gallon polyethylene tank provides self-contained water storage on remote acreage
- Wide 15-inch pneumatic turf tires distribute ground pressure across delicate lawn grass
- Universal clevis pin hitch connects behind riding mowers and garden utility vehicles
- Five quick-connect spray nozzles adjust fluid angles for tailored surface prep work
- Durable 25-foot pressure hose reaches equipment perimeters without repositioning the trailer
Bench Telemetry Load Results
Dynamometer bench testing demonstrates 3470 RPM engine output under 2650 PSI sustained pressure. Water discharge measures 2.42 GPM through the included size 030 nozzle tip. Engine oil temperatures reach 182°F after 2 continuous hours of towing wash operation. Gasoline consumption registers 0.54 GPH under working load. Sound meters record 86 dBA at 5 meters from the trailer hitch.
Worksite Performance Practical Notes
You hitch this compact trailer behind utility vehicles for rapid transport across pastures. The low frame height allows fast visual fluid checks through the translucent tank wall. Do not pull this loaded fluid cart at high speeds across steep slopes. Liquid surging shifts weight across the axle and causes loss of tow vehicle traction.
- Check tire pressure before filling the fluid storage tank with water
- Clean the inline tank discharge filter screen to block floating water debris
- Drain the water tank and pump passages completely before winter freezing weather
Certified Warranty Complete Manifest
Agri-Fab backs the trailer and tank with a 3-Year limited consumer warranty. The delivered carton contains the tow-behind cart, 60-gallon tank, 25-foot hose, spray gun, wand, 5 quick-connect spray tips, clevis pin hardware, and operator manuals.
